WIRELESS

• Working Modes: Range Extender/Access Point

HARDWARE FEATURES

• Standards and Protocols: IEEE802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11a, IEEE 802.11b
  Plug Type: EU, UK, US
• Interface: 1 x 10/100Mbps Ethernet Port (RJ45)
• Button: WPS Button, Reset Button
• Input Power: 100-240V~50/60Hz
• Max. Power Consumption: 7.3W（max power consumption）
• Dimensions ( W x D x H ): 3.1 x 3.0 x 3.0 in. (80 x 78 x 77mm)
• Antenna: 2 x external

WIRELESS FEATURES

• Wireless Standards: IEEE 802.11a/n/ac 5GHz, IEEE 802.11b/g/n 2.4GHz
• Frequency: 2.4GHz & 5GHz(11ac)
• Signal Rate:

  • 5GHz:Up to 867Mbps
  • 2.4GHz:Up to 300Mpbs
• Working Modes: Range Extender/Access Point
• Reception Sensitivity

  • 5GHz
  • 11a 6Mbps:-91dBm@10% PER
  • 11a 54Mbps: -74dBm@10% PER
  • 11ac HT20 mcs8: -68dBm@10% PER
  • 11ac HT40 mcs9: -63dBm@10% PER
  • 11ac HT80 mcs9: -59dBm@10% PER
  • 2.4GHz
  • 11g 54M: -79dBm@10% PER
  • 11n HT20 mcs7: -77dBm@10% PER
  • 11n HT40 mcs7: -74dBm@10% PER
• Wireless Modes:

  • Range Extender/Access Point
  • Wireless Statistic
  • Concurrent Mode boost both 2.4G/5G Wi-Fi band
• Wireless Functions:

  • Wireless Statistic
  • Concurrent Mode boost both 2.4G/5G Wi-Fi band
  • Access Control
  • LED Control
  • Domain Login Function
• Wireless Security:

  • 64/128-bit WEP
  • WPA-PSK / WPA2-PSK
• Transmission Power:

  • <17dBm(2.4GHz)
  • <17dBm(5GHz)
• Mesh Technology: EasyMesh-Compatible

FEATURES:

• Brings Wi-Fi dead zone to life with strong Wi-Fi expansion at combined speed of up to 1.2Gbps
• Operates over both the 2.4GHz band(300Mbps) and 5GHz band(867Mbps) for more stable wireless experience
• Intelligent signal light helps to fi­nd the best location for optimal Wi-Fi coverage by showing the signal strength
• Works with any Wi-Fi router or wireless access point
