Processor Intel® Core™ i5-10400, 12M Cache, up to 4.30 GHz

Processor Number : i5-10400
Lithography : 14 nm


CPU Specifications

Total Cores : 6
Total Threads : 12
Max Turbo Frequency : 4.30 GHz
Intel® Turbo Boost Technology 2.0 Frequency : 4.30 GHz
Processor Base Frequency : 2.90 GHz
Cache : 12 MB Intel® Smart Cache
Bus Speed : 8 GT/s
TDP : 65 W

Supplemental Information
Launch Date : Q2'20
Embedded Options Available : No
Use Conditions : PC/Client/Tablet


Memory Specifications

Max Memory Size (dependent on memory type) : 128 GB
Memory Types : DDR4-2666
Max # of Memory Channels : 2
Max Memory Bandwidth : 41.6 GB/s
ECC Memory Supported : No


GPU Specifications

GPU Name : Intel® UHD Graphics 630
Graphics Base Frequency : 350 MHz
Graphics Max Dynamic Frequency : 1.10 GHz
Graphics Video Max Memory : 64 GB
4K Support : Yes, at 60Hz
Max Resolution (HDMI) : 4096 x 2160@30Hz
Max Resolution (DP): 4096 x 2304@60Hz
Max Resolution (eDP - Integrated Flat Panel) : 4096 x 2304@60Hz
DirectX* Support : 12
OpenGL* Support : 4.5
Intel® Quick Sync Video : Yes
Intel® InTru™ 3D Technology : Yes
Intel® Clear Video HD Technology : Yes
Intel® Clear Video Technology : Yes
# of Displays Supported : 3
Device ID : 0x9BC8 / 0x9BC5


Expansion Options

Scalability : 1S Only
PCI Express Revision : 3.0
PCI Express Configurations : Up to 1x16, 2x8, 1x8+2x4
Max # of PCI Express Lanes : 16


Package Specifications

Sockets Supported : FCLGA1200
Max CPU Configuration : 1
Thermal Solution Specification : PCG 2015C
TJUNCTION : 100°C
Package Size : 37.5mm x 37.5mm


Advanced Technologies

Intel® Optane™ Memory Supported : Yes
Intel® Thermal Velocity Boost : No
Intel® Turbo Boost Max Technology 3.0 : No
Intel® Turbo Boost Technology : 2.0
Intel® Hyper-Threading Technology : Yes
Intel® Transactional Synchronization Extensions : No
Intel® 64 : Yes
Instruction Set : 64-bit
Instruction Set Extensions : Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
Idle States : Yes
Enhanced Intel SpeedStep® Technology : Yes
Thermal Monitoring Technologies : Yes
Intel® Identity Protection Technology : Yes


Security & Reliability

Intel® Secure Key : Yes
Intel® AES New Instructions : Yes
Intel® Software Guard Extensions (Intel® SGX) : Yes with Intel® ME
Intel® OS Guard : Yes
Intel® Trusted Execution Technology : No
Execute Disable Bit : Yes
Intel® Boot Guard : Yes
Intel® Stable IT Platform Program (SIPP) : No
Intel® Virtualization Technology (VT-x) : Yes
Intel® Virtualization Technology for Directed I/O (VT-d) : Yes
Intel® VT-x with Extended Page Tables (EPT) : Yes
